旁路放风与高硫煤的应用

doi:10.19698/j.cnki.1001-6171.20204065

下载:

PDF (1984KB)
输出: BibTeX | EndNote (RIS)

摘要某5 000t/d熟料生产线原、燃材料硫、氯元素含量高，需采用旁路放风系统降低硫、氯元素含量。通过采用经典的Weber法计算了旁路放风量，设置旁路放风量10%的放风系统，放风点设置在窑尾烟室斜坡部正前方。旁路放风量为10%时，热损失不大，排灰量为20g/kg，窑尾结皮减弱，熟料有害成分含量大幅降低，熟料性能改善，技术经济效益可观。

	服务
	把本文推荐给朋友
	加入引用管理器
	E-mail Alert
	RSS
	（）
	作者相关文章
	刘庆江
	高增毅
	方婉
	沈欣

关键词: 旁路放风氯元素放风量排灰量

Abstract: A 5 000t/d production line has a high content of sulfur and chlorine element , it needs to adopt by-pass system. The traditional Weber method is used to calculate the by-pass air volume, and a 10% by-pass system is set up, and the gas drawing point is set in front of the slope of the kiln inlet chamber. The heat loss of 10% ventilation is appropriate, the ash discharge is 20g/kg.cl, the crust at the end of kiln is weakened, the content of harmful components in clinker is greatly reduced, and the performance of clinker is improved.

Key words: bypass chlorine element bypass vent volume ash discharge

收稿日期: 2020-01-13 出版日期: 2020-07-25 发布日期: 2020-07-27 整期出版日期: 2020-07-25

ZTFLH:

TQ172.622.29

引用本文:

刘庆江, 高增毅, 方婉, 沈欣. 旁路放风与高硫煤的应用[J]. 水泥技术, 2020, 1(4): 65-70.
LIU Qingjiang, GAO Zengyi, FANG Wan, SHEN Xin. Bypass Ventilation and Application of High Sulfur Coal. Cement Technology, 2020, 1(4): 65-70.
