栓焊结合钢网架熟料库屋盖设计与施工安装
中建材(合肥)钢构科技有限公司,安徽  合肥  230051
Design and Installation of Bolted and Welded Steel Grid for Clinker Silo Roof
 CNBM (Hefei) Steel Structure Technology Co., Ltd. , Hefei Anhui 230051, China
下载:  PDF (4924KB)
输出:  BibTeX | EndNote (RIS)
摘要
介绍了螺栓球节点与焊接球节点相结合的钢网架(壳)结构熟料库屋盖设计的思路,采用MST和3D3S软件进行网架结构设计计算,并建立全钢结构整体模型,经复核验算,焊接球节点强度符合规范要求。使用焊接球与螺栓球节点相结合的网架体系,支座环向杆件无需使用大直径螺栓,降低了施工难度,节省了建造材料和建造成本。
服务
把本文推荐给朋友
加入引用管理器
E-mail Alert
RSS
作者相关文章
朱玉林
关键词:  熟料库  焊接球节点  螺栓球节点  钢网架
Abstract:
This paper introduces the design idea of steel grid(shell) structure clinker silo roof combining bolt sphere joints and welded sphere joints, uses MST and 3D3S software to design and calculate the grid structure, and establishes an overall steel structure model. After reverification, the strength of welded sphere joints meets the requirements of the specification. The grid structure system combining welded sphere and bolt sphere joints is used, and the support circumferential members do not need to use large diameter bolts, which reduces the construction difficulty and saves the construction materials and construction costs.
Key words:  clinker silo    welded spherical joint    bolt sphere joint    steel grid
收稿日期:  2022-04-12      修回日期:  2022-11-25           出版日期:  2022-11-25      发布日期:  2022-11-25      整期出版日期:  2022-11-25
ZTFLH:  TU356
基金资助: 合肥水泥研究设计院有限公司科研开发项目(GG01-2021);安徽省住房城乡建设科学技术计划项目(2022-YF106)
引用本文:
朱玉林. 栓焊结合钢网架熟料库屋盖设计与施工安装[J]. 水泥技术, 2022, 1(6): 57-62.
ZHU Yulin. Design and Installation of Bolted and Welded Steel Grid for Clinker Silo Roof. Cement Technology, 2022, 1(6): 57-62.
