万吨水泥生产线回转窑驱动系统的改造
1 徐州中联水泥有限公司,江苏  徐州  221011; 2 弗兰德传动系统有限公司,天津  300400
Renovation of the Drive System of Rotary Kiln on 10 000t/d Cement Production Line
1. China United Cement Xuzhou Co., Ltd. , Xuzhou Jiangsu 221011, China;2. Flender Drive System Ltd. , Tianjin 300400, China
下载:  PDF (3320KB)
输出:  BibTeX | EndNote (RIS)
摘要 徐州中联万吨水泥熟料生产线?6m×90m回转窑原有驱动系统已无法满足企业降本增效、节能减排需求,在最大限度保持驱动系统安装尺寸不变的情况下,通过重新选型减速机,窑转速最大可达5r/min;通过对润滑油站优化设计,解决了减速机冷却润滑不足、油温高的问题;通过安装锁紧盘、调整扭力臂以及万向节联轴器等,解决了齿轮箱偏载振动大的问题。改造后的回转窑设备运行平稳,满足了系统提产提速的要求。
服务
把本文推荐给朋友
加入引用管理器
E-mail Alert
RSS
作者相关文章
王科学
纪良
王明乾
关键词:  回转窑  驱动系统  减速机  扭力臂
Abstract: The original drive system of ?6m×90m rotary kiln equipment of 10 000t/d cement production Line used in Xuzhou CUCC could no longer meet the requirement of company's cost reduction and efficiency demand, energy conservation and emission reduction. Based on this problem, the rotary kiln will have a maximum speed of 5r/min by reselecting the gearbox, while maximum keeping the installation size of drive system consistent. Through the optimization design of the lubricating oil station, the problems of insufficient cooling and lubrication of gearbox and high oil temperature can be solved. Furthermore, the problem of abnormal vibration under leaning load can be solved by readjusting shrink disc, torque arm and universal joint coupling. After solving above problems, the rotary kiln equipment runs stably and meets the requirements of system to increase production and speed.
Key words:  rotary kiln    drive system    gearbox    torque arm
